SIRAX SH100 Shunts



SHUNTS

SIRAX SH100
The shunts are used to measure DC currents, especially at high current levels.
  • Primary creent ratings 1A ... 15000A available
  • Voltage drop 50mV, 60mV, 75mV, 100mV and 150mV available
  • Rugged construction
  • High accuracy class 0.2 and 0.5
  • Busbar mounting
  • High overload resistance
  • Very low temperature coefficient
  • high long-term stability
  • Shock and vibration proof






Application






Dimensional drawings



SIRAX SH100
